Pressure Systems, Inc. 98RK-1 & 9816 User’s Manual©
Page 68 www.PressureSystems.com
Command 'c' — Sub-command Index 04: Return Stream Information
This sub-command returns current stream configuration information in its response:
Command
"c 04 st"
‘c’ is the command letter.
‘ 04’ is the sub-command index (ii) for Return Info.
‘ st’ is the stream id digit (1, 2, or 3, =0 no allowed).
NOTE: all parameters are separated by a space.
Response
“st [[[[p]p]p]p]p sync per f num”
‘st’ is the stream identifier digit (1, 2, or 3).
‘ ppppp’ is a 1-5 hex digit position field (channel selection bit
map).
‘ sync’ is sync type character (0 or 1).
‘ per’ is the period (# trigger periods or delay timer period).
‘ f’ is the format of the data delivered in stream.
‘ num’ is the number of packets delivered in the stream.
NOTE: all datum fields are separated by a space.
Autonomous
Packet
none generated
Description: This sub-command returns current configuration information for a particular
stream. Returned values are defined the same as the sub-command parameters
of Configure a Host Delivery Stream (sub-command 00). Note that the ‘num’
field represents the number of packets returned so far (= last sequence number
returned, or =0 if stream not yet started).
Example:
● Return scan list information for stream l
"c 04 1"
Read
response:
"1 FFFF 0 20 7 32000"
