Krautkramer USN 52R/USN 52L Issue 05, 02/00 5-37
Clearing FILES
All cleared data are irrevocably lost. Therefore, transfer
the data to a PC or printer beforehand if necessary.
Operation:
– Change to the second operating level and select the
function group for the Data Logger.
– Select the data set in FILE NUMBER which you
wish to delete. Select ALL CLEAR to completely
delete the Data Logger.
A
Attention:
All deleted data are irretrievably lost!
– Simultaneously press M in FILE NUMBER and
keep it pressed for about 3 seconds.
When the FILE status “EMPTY” or “ALL CLEAR” is
displayed, the selected FILE or the complete contents
of the Data Logger are cleared.
Storing measured values
A measured value is only stored if it is not equal to 0
and if the active measurement location is empty. To
start with, set the following values:
FILE NUMBER: EMPTY or ACTIVE
FILE MODE: THICKNESS
COPY MODE: DATA LOGGER
MEASURE: 0 TO 1st or MULTECHO
The thickness value is displayed in the A-scan mode at
the top right-hand side. The measurement line shows:
• LOC: the memory slot number of the selected FILE.
The next measured value will be stored here.
• VAL: the value which is stored on the displayed
measurement location.
Operation:
Press A to store the measured value.
H Note:
You should transfer data to a PC in order to save them
permanently. You can order the software which is re-
quired for data transfer from Krautkrämer (refer to Chap-
ter 2).
Storing measured values - Data Logger Operation
