5-58 Issue 05, 02/00 Krautkramer USN 52R/USN 52L
COPY MODE Setting data communication
In this function you select the data transfer mode when
you press A:
• HARD COPY:
Printout of complete display
• REPORT:
Printout of Data Logger report
• THICKNESS:
Transfer of thickness value
• DATA LOGGER:
Prerequisite for enabling the Data Logger
• DISP + PDUMP:
Printout of A-scan and report
• PARAMETER DUMP:
Printout of parameter dump with remote codes and
actual settings.
• MEMO DUMP:
Printout of the additional informations of the MEMO
function.
Operation:
– Highlight the center function group in the center
function table with I.
– With M select the required setting in the COPY
MODE.
Printer type
Additionally, you select in this function the printer for
which the printouts are formatted:
• EPSON FX (also for EPSON LX-300)
• SEIKO DPU 411 (also for Seiko DPU 414)
Operation:
– Simultaneously press N and O in the function
COPY MODE.
The function changes in PRINTER SELECT.
– Select the required printer driver with M.
– Simultaneously press N and O again in order to exit
this function.
Operation Setting the RS232 interface
5-58 Issue 05, 02/00 Krautkramer USN 52R/USN 52L
COPY MODE Setting data communication
In this function you select the data transfer mode when
you press A:
• HARD COPY:
Printout of complete display
• REPORT:
Printout of Data Logger report
• THICKNESS:
Transfer of thickness value
• DATA LOGGER:
Prerequisite for enabling the Data Logger
• DISP + PDUMP:
Printout of A-scan and report
• PARAMETER DUMP:
Printout of parameter dump with remote codes and
actual settings.
• MEMO DUMP:
Printout of the additional informations of the MEMO
function.
Operation:
– Highlight the center function group in the center
function table with I.
– With M select the required setting in the COPY
MODE.
Printer type
Additionally, you select in this function the printer for
which the printouts are formatted:
• EPSON FX (also for EPSON LX-300)
• SEIKO DPU 411 (also for Seiko DPU 414)
Operation:
– Simultaneously press N and O in the function
COPY MODE.
The function changes in PRINTER SELECT.
– Select the required printer driver with M.
– Simultaneously press N and O again in order to exit
this function.
Operation Setting the RS232 interface
