Krautkramer USN 52R/USN 52L

Issue 05, 02/00

10-3

Function

Description

a-START (GATE)

Selection of the start point of the corresponding gate

a-THRESH (GATE)

Adjustment of the level of the gate threshold in % of screen height

a-WIDTH (GATE)

Adjustment of the gate width related to the start point of the corresponding gate

AMPLITUDE (left)

Selection of the measurement mode for the evaluation of the flaw amplitude

ANGLE (center)

Entry of the probe’s angle for calculation of the flaw location

ASCAN (center)

Setting the echo display (as outline or filled)

AUTO CAL (right)

Enables automatic calibration

BAUD RATE (right)

Adjustment of the baud rate for data transfer via the RS232 interface

COPY MODE (center)

Selection of type and form of printout

CURVE (TCG)

Display of DAC curve

DAC ECHO (TCG)

Number of reference echoes of the DAC curve; storage of one reference echo in the
recording mode (REC)

DAC/TCG (TCG)

Setting of DAC/TCG function

DAMPING (RCVR)

Setting of damping resistor

Function directory

Appendix
