Krautkramer USN 52R/USN 52L

Issue 05, 02/00

6-3

H Note:

In cases of doubt, refer to the technical specifications
of the connected device. This is the only way to ensure
error-free communication.

In the function COPY MODE of the same function
group you select which data are to be printed:

• HARD COPY: Printout of the display contents

• REPORT: Printout of the Data Logger contents

• THICKNESS: Transfers the thickness value. When

angle function is enabled, the values for S=, P= and
D= are transferred.

• DATA LOGGER: The Data Logger is enabled for

storage of the measured values. When A is pressed,
a measured value is transferred to the Data Logger.

• DISP+PDUMP: Prints the A-scan and a single-page

test report with all settings relevant to the test.

• PARAMETER DUMP: Prints a list of all USN 52 R

functions including remode codes and actual
settings.

• MEMO DUMP: Prints the additonal information

added with the active MEMO function.

You can also select the printer:

Press N and O simultaneously in the function
COPY MODE.

The function PRINTER SELECT appears. You can
select the following printers:

• EPSON FX (also for EPSON LX-300)

• SEIKO DPU 411 (also for Seiko DPU 414)

– Select the required printer with M.

– Simultaneously press N and O again in order to exit

the function PRINTER SELECT.

You are now in the COPY MODE again.

– By activation of A you can transfer the data to a

printer or to the Data Logger.

Printing instrument settings and display contents

Documentation
