4-6 Issue 05, 02/00 Krautkramer USN 52R/USN 52L
Indications beneath the A-scan
Measurement line
The current measurement results are displayed here.
The contents of this line depend on the settings of the
functions MEASURE, TOF, AMPLITUDE, FILE MODE,
ANGLE and X-VALUE.
Basics of operation Display
Status line
Symbols appear here which indicate certain settings,
e.g. battery charge status (please refer to fold-out
page).
