Krautkramer USN 52R/USN 52L Issue 05, 02/00 4-11
Selection of measured value for enlarged
display
Using U in the measurement line select the value
which is to be enlarged on the display.
With U you also can toggle between graticule scaling
in scale divisions (Div.) and display of the RANGE/
DELAY in the measurement line. For this, either the
function GATE LOGIC or MEASURE must be set to
OFF (both functions: lower operating level).
4.4 Function keys
With the function keys you select functions and change
the indicated settings:
Key Function
K Switches the USN 52 R on and off
F Returns to the first operating level and to
the BASIC function group
U Selects measured values or function tables
I Selects function group.
M Changes active setting
X Change of operating level
Operational concept Basics of operation
Krautkramer USN 52R/USN 52L Issue 05, 02/00 4-11
Selection of measured value for enlarged
display
Using U in the measurement line select the value
which is to be enlarged on the display.
With U you also can toggle between graticule scaling
in scale divisions (Div.) and display of the RANGE/
DELAY in the measurement line. For this, either the
function GATE LOGIC or MEASURE must be set to
OFF (both functions: lower operating level).
4.4 Function keys
With the function keys you select functions and change
the indicated settings:
Key Function
K Switches the USN 52 R on and off
F Returns to the first operating level and to
the BASIC function group
U Selects measured values or function tables
I Selects function group.
M Changes active setting
X Change of operating level
Operational concept Basics of operation
