Krautkramer USN 52R/USN 52L Issue 05, 02/00 3-5
3.3 Probe connection
The probe connections are on the lower right of the
front panel.
Connect straight-beam probes to the red socket (Re-
ceive - right). With T/R probes, connect the pulser cable
to the green socket (left) and the receiver cable to the
red socket (right).
– Set the pulser power as follows:
– Switch the USN 52 R on with K.
– Select the function group RCVR by pressing C.
– Using N or O, set the damping resistor in function
DAMPING There are 4 settings available: 50, 75, 150
and 1000 ohms.
3.4 Starting the USN 52 R
Switching on
This is the normal way of switching on the USN 52 R.
– Press the switch-on key K in the operator’s control
panel.
After a short time, the start display appears with infor-
mation about the applied software version and about
the instrument configuration.
The settings for all function values and default settings
are the same as before switching off.
Probe connection Setting into operation
Krautkramer USN 52R/USN 52L Issue 05, 02/00 3-5
3.3 Probe connection
The probe connections are on the lower right of the
front panel.
Connect straight-beam probes to the red socket (Re-
ceive - right). With T/R probes, connect the pulser cable
to the green socket (left) and the receiver cable to the
red socket (right).
– Set the pulser power as follows:
– Switch the USN 52 R on with K.
– Select the function group RCVR by pressing C.
– Using N or O, set the damping resistor in function
DAMPING There are 4 settings available: 50, 75, 150
and 1000 ohms.
3.4 Starting the USN 52 R
Switching on
This is the normal way of switching on the USN 52 R.
– Press the switch-on key K in the operator’s control
panel.
After a short time, the start display appears with infor-
mation about the applied software version and about
the instrument configuration.
The settings for all function values and default settings
are the same as before switching off.
Probe connection Setting into operation
