Interfaces for Temperature Measurement
Cable gland Multiple feed-through
Sealing range of cable gland 3.2 mm to 6.5 mm
* based on the measurement range end value (with four-wire measurement)
Digital Input (Customer)
Quantity 1
Supply voltage 24 V
DC
±20%
Maximum output current (for sensors) 150 mA
Switching threshold, low level V
LMAX
3 V
Switching threshold high level V
HMIN
15 V
Nominal input voltage 24 V
DC
Nominal input current 5 mA
Terminal Spring-cage terminal with actuation lever on the
electronic assembly
Conductor cross-section 0.08 mm 2 to 1.00 mm 2
Maximum cable length 30 m
Cable gland Multiple feed-through
Sealing range of cable gland 3.2 mm to 6.5 mm
Digital Input for Alarm Contact* for DC Load-Break Switch
Quantity 1
Design Potential-free contact
Nominal input voltage (typical) 24 V
DC
Nominal input current (typical) 5 mA
Terminal Supplied preassembled cable with plug contact
* available as an accessory (see Section 14, page 72)
Analog Current Input
Quantity 1
Supply voltage 24 V
DC
±20%
Maximum output current (for sensors) 150 mA
Input measurement resistance 250 Ω
Current measurement range 4 mA to 20 mA
Maximum error at +25°C* ±0.3%
13 Technical Data SMA Solar Technology AG
Operating Manual 69 SSMUXX15-BE-en-10
