11 Technical Data
11.1 DC/AC
11.1.1 Sunny Tripower 5000TL / 6000TL / 7000TL
DC Input
STP 5000TL-20 STP 6000TL-20 STP 7000TL-20
Maximum DC power at cos φ =
1 5,100 W 6,125 W 7,175 W
Maximum input voltage 1,000 V 1,000 V 1,000 V
MPP voltage range 245 V to 800 V 295 V to 800 V 290 V to 800 V
Rated input voltage 580 V 580 V 580 V
Minimum input voltage 150 V 150 V 150 V
Initial input voltage 188 V 188 V 188 V
Maximum input current, input A 11 A 11 A 15 A
Maximum input current, input B 10 A 10 A 10 A
Maximum input current per
string, input A* 11 A 11 A 15 A
Maximum input current per
string, input B* 10 A 10 A 10 A
Maximum short-circuit current,
input A 16.5 A 16.5 A 22.5 A
Maximum short-circuit current,
input B 15 A 15 A 15 A
Number of independent MPP in-
puts 2 2 2
Strings per MPP input 2 2 2
* Maximum permitted current allowed through one DC connector.
AC Output
STP 5000TL-20 STP 6000TL-20 STP 7000TL-20
Rated power at 230 V, 50 Hz 5,000 W 6,000 W 7,000 W
Maximum apparent AC power
at cos phi = 1 5,000 VA 6,000 VA 7,000 VA
Rated grid voltage ∼3/N/PE, 230 V /
400 V
∼3/N/PE, 230 V /
400 V
∼3/N/PE, 230 V /
400 V
