216
Input Cards and Backplanes
3Gig/TDM (coax):
SD, HD, or 3Gig for
video, plus MADI
synchronous digi-
tal audio, unbal-
anced 8500H-IP-3G-
TDM-CX Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
(for cables listed, or equiva-
lent cables)
270 Mb/s,
400 m Belden 1694A,
250 m Belden 1855A
1.5 Gb/s
150 m Belden 1694A,
100 m Belden 1855A
3.0 Gb/s
100 m Belden 1694A,
45 m Belden 1855A
Audio: 1 stream of 64 chan-
nels, 24 bits, at 48 kHz,
locked to reference
8, video;
1 MADI
stream EM0904
(coax)
(for NV8140)
3Gig/TDM (coax):
SD, HD, or 3Gig for
video, plus MADI
synchronous digi-
tal audio, unbal-
anced
8140H-IP-3G-
TDM-CX Hybrid Video rates from 19 Mb/s to
2.97 Gb/s.
(for cables listed, or equiva-
lent cables)
270 Mb/s,
400 m Belden 1694A,
250 m Belden 1855A
1.5 Gb/s
150 m Belden 1694A,
100 m Belden 1855A
3.0 Gb/s
100 m Belden 1694A,
45 m Belden 1855A
Audio: 1 stream of 64 chan-
nels, 24 bits, at 48 kHz,
locked to reference
16, video;
2 MADI
streams EM0888(
coax)
a. The EM0904 replaces the EM0791 which is its equivalent. (The EM0904 has better characteristics.)
Card and Signal
Type
Part Number
Card
Class
Rates Signals
Back-
plane
