201
Specifications
This section provides technical specifications for the NV8500 series hybrid routers, the NV8300
power supply, and the MADI interfaces.
Power Specifications (PS8100)
The NV8144 uses the PS8100 power supply module. For the NV8144, power supply modules are
installed in the router frame.
The following are power specifications for the PS8100:
Type Parameters
AC Input 90–130/180–250 VAC, 50/60 Hz, Auto-ranging. 15 Amp at 110 VAC;7.5 Amp
at 220 VAC.
AC Fuses No user serviceable fuses
AC Connectors 2, IEC 320-C13 (one for each PS8100 module installed)
AC Power PS8100, 850 Watts, one IEC 320-C13 (female), one NEMA 5-15p (male)
AC Power Usage 850 Watts nominal (144 × 144), power factor corrected
Power draws for fully loaded frame:
Coax 600 Watts
Fiber optic 820 Watts
Hybrid 820 Watts
Modules and
Module Slots Required minimum number of PS8100 modules:
1 primary (1 optional redundant)
Power Supply Alarm Con-
nection DE9; reads status from each PS8100
Power Supply Monitor
Connection DB25, loop-through possible
Cabling WC0109-00 — cable from NV8144 to power source
Environmental Operating temperature: 0 to 40° C
Relative humidity: 0 to 90%, non-condensing
Regulatory Compliance UL listed and CE compliant
