100 Acappella — Instruction Manual
Section 4 — Software and Configuration
Remote Panel Router Configuration
This Router Configuration page is used to select Levels to be used by the
Remote Panel.
Figure 51. Router Configuration Type
Select the Acappella Router Level type from the dropdown menu ( Table 5 )
and enter the IP Address of the router.
Check Do reset and click Save New Settings to apply selection.
Remote panels can use Levels from any Acappella frame in the system.
Table 5. Level Types
Acappella HD-R HD Wideband Digital Video Reclocking
Acappella SD-R SD Digital Video Reclocking
Acappella SD-B SD Digital Video Non-reclocking
Acappella AES AES/EBU Digital Audio
Acappella AES-1 AES/EBU Digital Audio Dual Stream 1
Acappella AES-2 AES/EBU Digital Audio Dual Stream 2
