Operation Section
21
How to read the heating capacity curve
ILL00882-00
35
(2)
40
(4)
45
(7)
50
(10)
55
(13)
60
(16)
65
(18)
70
(21)
75
(24)
80
(27)
85
(29)
Hea
ting cap
a
cit
y (kBtu/h)
Dry Bulb Temp. ºF (ºC)
Example: Dry bulb: 60 ºF (15.6 ºC), 50 %RH, High fan speed
Heating capacity:16 kBtu/h
10
12
14
16
18
20
Hi
Lo
Mid
