Mkiv unit 4 parts list – Harken 7413.10 MKIV Jib Reefing & Furling built after Feb. 2009 User Manual
Page 41
MKIV unit 4
41
MKIV Unit 4
Parts List
5
Description
Order Part No.
Instruction manual
1
4673
Blue Loctite
®
adhesive
1
833
Red Loctite
adhesive
2
HFG739
5200 adhesive set
1
HFG725
5200 marine adhesive sealant
1
HFG722
Injector
1
HFG200
HFG201
Prefeeder
1
947
Description
Order Part No.
Hex keys
M6
1
HFG644
M5
1
HFG643
6
6
4
Description
Order Part No.
Trim cap set w/o screws
1
HFG949
Trim cap screw set
1
HFG672
Trim cap screw
2
HFS1127
Halyard swivel
1
H-45788
Clip/smalley ring for balls
1
H-46469
Clip/smalley ring for liners
1
HCP1292
Torlon
®
ball bearings (
1
/
2
")
100
MP-128
Foil set
2
7414.10 FOILSET
Foil (7' / 2.13 m luff)
10
7414.30
Foil (2' / 610 mm) bottom
1
7414.33
Foil screw set
1
HFG948
Foil screw
48
HFS1176
Connector kit
1
7414.31
Connector
1
—
Connector bushing top
2
—
Connector bushing bottom
2
—
Bottom connector kit
1
7414.32
Bottom connector
1
—
Connector bushing top
2
—
Connector bushing bottom
2
—
Connector
9
7414.31
Bottom connector (247 mm / 9
3
/
4
" )
1
7414.32
Connector bushing set
1
HFG946
Connector bushing top
(curved/longer)
23
H-45542
Connector bushing bottom
(flat/shorter)
23
H-45543
Plastic connector wedge set
1
HFG947
Plastic connector wedge
24
H-45509
Feeder tab
1
H-45482
Screw
1
HFS1175
M6
M5
HFG948
HFG672
4
HFG949
7414.30
H-45542
7414.31
H-39756
7414.32
7414.10 FOILSET
7414.33
H-455434
HFG946
HFG947
H-45788
H-46469
HCP1292
MP-128
MP-128
MP-128
5
HFG739
4673
HFG722
HFG200/HFG201
HFG947
833
