Harken 7413.10 MKIV Jib Reefing & Furling built after Feb. 2009 - Manual (Page 4)

Preassembly Parts
4 MKIV units 3, 4
Drum assembly
unit 3
Main components
Description Unit Part No. Qty
Drum assembly with clamp
3
HFG944 1
610 mm (2') bottom foil 7413.33 1
2.13 m (7') foil 7413.30 10
Halyard swivel H-39392 1
Blue Loctite ® adhesive 833 1
Drum Assembly
4
HFG945 1
610 mm (2') bottom foil 7414.33 1
2.13 m (7') foil 7414.30 10
Halyard swivel H-45788 1
Blue Loctite ® adhesive 833 1
Drum assembly
unit 4
Halyard swivel
unit 4
2.13 m (10 - 7') foils
Unit 3, 4
610 mm (2')
bottom foil
Blue Loctite ®
adhesive
Loctite is a registered trademark of Henkel AG & Company KGaA.
Halyard swivel
unit 3
