Assembly unit 3, 4—attach toggle/short link plate – Harken 7413.10 MKIV Jib Reefing & Furling built after Feb. 2009 User Manual
Page 24
Assembly
Unit 3, 4—Attach Toggle/Short Link Plate
24
MKIV units 3, 4
Recess turnbuckle into drum assembly, slip link
plates over special clevis pin, and secure using
fasteners. Use blue Loctite
®
adhesive on screws.
Secure to toggle using lock nuts.
Apply isolator.
Loctite is a registered trademark of Henkel AG &
Company KGaA.
