GASBOY Series 9800Q

3-8

01/28/04

$GGUHVV

Closed

Open

Closed

Open

Closed

Open

6: 6:

Open

Closed

Open

Closed

Open

Closed

Open

Closed

Open

Closed

Open

Closed

Closed
Open

Open
Open

Closed
Closed

Closed

Open

Closed

Open

Closed

Open

Closed

Closed Open

Open

SW2
This four-position switch pack serves a dual purpose: as an address setting when communicating
on the GASBOY RS-485 loop or Series 900, or as a pulser output rate selector when pulser data
is sent to a fuel management system other than a GASBOY CFN or Series 900.

Address Switches
A unique address identifier must be set when the
9800Q is connected to the GASBOY RS-485
pump loop via the 9800Q RS-485 I/F PCB.

Because there are 16 possible address
combinations, up to 16 units (single or twin) may
be connected to the pump loop. Addressing
should start at 1 and continue sequentially through
16. The physical wiring order does not have to
correspond with the address order; that is the first
unit on the RS-485 loop doesn’t have to be
address 1. The chart at right gives the switch
settings and address selections. With the Series
900 option, the address must be set to 1.

Pulser Output Rate Switches
When the 9800Q is connected to external
control equipment other than a GASBOY
CFN system (standalone), the pulser signals
are sent out via the 9800Q Pump I/F PCB.
The pulse rate required by the monitoring
equipment can be configured by setting the
switches as shown in the chart at right. The
pulse rate represents pulses per gallon
(PPG, domestic) or pulses per liter (PPL,
international). For domestic units, the pulse
rate can be up to 500 PPG for 9840Q and
up to 1000 PPG for all other models. For
international units, the pulse rate can be up
to 100 PPL for 9840Q and up to 250 PPL for
all other models. This switch may need to
be sealed by a Weights and Measures
paper seal if the 9800Q is used for the
resale of product.

Leading zeros are always suppressed in the
hundreds and tens positions to the left of the
decimal point. When in standalone mode,
positions to the right of the decimal point are
displayed based on the pulse rate selected
as shown in the table at right.

Pulse

Rate

SW2-1 SW2-2 SW2-3

Closed Closed Closed

10 Open

Closed

100 Closed

Open

Closed

250 Open Open Closed
500

Closed Closed Open

1000 Open Closed

Open

None Closed

Open Open

None Open Open Open

Pulse Rate

Display

1:1 XXX.

10:1 XXX.X

100:1 XXX.XX
250:1 XXX.XXX
500:1 XXX.XXX

1000:1 XXX.XXX

Timeout Switch
When the 9800Q is in standalone mode, it will turn off an active
hose if it doesn’t detect pulses for 4 minutes, 15 seconds. This
timeout feature can be disabled by setting switch SW2-4 to
Open.

Timeout SW2-4
Enabled Closed
Disabled

Open
