Formax 6606 Series - Manual (Page 146)

Specifications 11
Technical Specifications
Model
Type
Theoretical max. speed
Power consumption
Voltage tolerance
Fuse
Approvals
Noise Level
Operating temperature
FD6606
Folder and inserter system for
medium
office use.
4
,300 inserts per hour, depending on
application.
100V
AC/50Hz/4.0 Amps.
115V
AC/50/60Hz/4.0 Amps.
230V
AC/50Hz/2 Amps.
100V:
+6% / -10%
115V:
+6% / -10%
230V:
+10% / -10%
100/115
Vac: T 5.0 A, 125 V .
Time
lag, 5.0 Amps. rated current, 125 V.
230
Vac: T 3.15 A H, 250 V.
Time
lag, 3.15 Amps. rated current, high
breaking
capacity, 250 V.
EMC
Certificate conform EMC-Directive.
FCC
Certificate conform 47CFR, part 15
CB
Certificate conform IEC 60950-1
UL
Listed I.T.E. (Information Technology
Equipment)
Conform
UL-IEC 60950-1, file E153801
Conform
NEN-EN-IEC 60950-1 and derivat-
ives.
<70
dBA (according to ISO 11202)
10°C
- 40°C (50°F-104°F)
30%-80%
Humidity
142
