4.4.3 Web Server Interface Operation
4.4.3.1 Menu Tree
This menu tree diagram shows the menus and pages in the LPOD-R Web Server Interface. This
interface has four top level navigation tabs, shown in blue. Each top level tab has secondary
level page hyperlinks (grey). Page hyperlinks open individual Web pages.
Home Admin Config Status
Home Access Amplifier Summary
Contact SNMP Utility Status
Support Events
Statistics
4.4.3.2 Page Navigation
The Web Server Interface has four navigation tabs at the top of each
page. Click a navigation tab to see its page hyperlinks. Click a page
hyperlink to open a page.
This manual uses a convention for all web pages to show you how to navigate to the referenced
page: Navigation Tab | Page Hyperlink.
For example, Home | Home means click the Home navigation tab, and then click the Home page
hyperlink.
4.4.3.3 Page Sections
Each page has one or more sections. The title at the upper-left corner
of each page or section describes its operational features. Each
section can have editable fields, action buttons and read-only
displays for a specific function. This manual explains the purpose and
operation for each Web page and its sections.
4.4.3.4 Action Buttons
Action buttons are important in the LPOD-R Web Server Interface. Click an
action button to do one of these tasks:
• Refresh the page with current data.
• Reset changed parameters to remove unsaved changes.
• Submit (save) changes.
If you change any parameters, make sure to click the related action button before you
leave the page. If you go to another page without first clicking the action button, your
changes are not saved.
