LPOD-R Outdoor Amplifier / Block Up Converter (BUC) MN-LPODR
Optional Serial-based Remote Product Management Revision 1
5–19
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to
Query
(Target to
Controller)
Retrieve
Alarm Status
(cont)
SHTDN=OK’cr’ Over-temp shutdown
IICST=OK’cr’ I2C bus status
FWPWR=MS’cr’ Forward power in dBm
CHKSM=OK’cr’ Flash checksum
FPGAD=NA’cr’ FPGA done status
BUCLD=OK’cr’ BUC lock detect
REFLD=NA’cr’ Reference lock detect
LNBCS=NA’cr’ LNB current status
SWITC=NA’cr’ Waveguide switch position status
RDLNK=NA’cr’ Redundant link status
TRMST=YS’cr’ Terminal Status
UNAFW=OK’cr’’lf’ Unaccepted Firmware
Note: Field values display when the appropriate model/options are selected/installed. Otherwise, unused fields display NA.
Reboot RBT= 1 byte Command only.
Performs a Soft Reboot of the unit, where:
1 = Reboot System
Example: <1/RBT=’cr'
RBT=
RBT?
RBT*
N/A RBT=x
(See Description
of Arguments for
details)
Retrieve
Configuration
Status
N/A 45 bytes Query only.
Returns the configuration status of the unit, where:
ATT= attenuation, in dB
AMP= RF power amplifier state:
0=OFF
1=ON
MUT=RF mute state:
0=unmuted
1=muted
RED=Online status for redundancy
ESW=Redundancy state and mode state:
0=OFF
1=ON Tx only
2=ON Tx & Rx
AOF=Attenuator Offset, in dB
AFR= auto fault recovery
0 = manual
1 = auto
XRF = External reference status:
N/A = no external reference
05M = 5 MHz
10M = 10 MHz
RCS= RCS? RCS=x….x
(See Description
of Arguments for
details)
