LPOD-R Outdoor Amplifier / Block Up Converter (BUC) MN-LPODR
Optional Serial-based Remote Product Management Revision 1
5–20
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to
Query
(Target to
Controller)
Retrieve
Configuration
Status (cont)
Example:
<1/RCS?’cr’
>0001/RCS=’cr’
ATT=12.75’cr’
AMP=1’cr’
MUT=1’cr’
ONL=1’cr’
ESW=1’cr’
AOF=00.00’cr’
AFR=1’cr’
XRF=N/A’cr’’lf’ (see Note 2)
Notes:
1) Unused fields shall be padded with X’s.
2) XRF is always N/A when the internal reference oscillator option is not installed.
Retrieve
Equipment
Type E
N/A 22 bytes Query only.
Returns a string indicating the Model Number and the version of the installed M&C firmware.
Example: <1/RET?’cr’
>0001/RET=LPOD-R VER: 1.1.1’cr’’lf’
RET= RET? RET=x….x
(See Description
of Arguments for
details)
Retrieve
Maintenance
Status
N/A 213 bytes
alphanumeric
Query only.
Returns the maintenance status of the unit, where:
LINEV = LINE voltage
LINEA = LINE amperage
LNBVT = +13/18V LNB power supply (see Note)
P13VT = +13.5V power supply
P10V1 = +10V1 power supply
A10V1 = 10V1 on RF Module
A10V2 = 10V2 on RF Module (see Note)
P7V8T = +7.8V power supply
P5V8T = +5.8V power supply
P2V5T = +2.5V power supply
P1V2T = +1.2V power supply
N5V8T = -5.8V power supply
FAN1V = Fan 1 voltage
FAN1A = Fan 1 current
BUCVT = BUC tuning voltage (see Note)
FWPWR = Forward power in dBm
REFVT = Reference osc. tuning voltage (see Note)
LNBCS = LNB current supply in mA (see Note)
ATEMP = Heatsink temperature in Celsius
OTEMP = Outdoor temperature in Celsius (see Note)
RMS= RMS? RMS=x….x
(See Description
of Arguments for
details)
