A-1
Appendix A. CABLE DRAWINGS
A.1 Overview
This appendix provides line details for the cables available for use with the LPOD-R in Standalone applications. Each figure illustrates the
cables technical specifications – e.g., connector types used, cable labeling, wiring lists, etc.
A.2 Control and Data Cables
Figure
CEFD
CABLE P/N
DESCRIPTION USED FOR:
A-1 CA-0020526
Serial Interface Cable
(19-pin circular connector to RJ-11)
Connecting standalone LPOD-R PS 1 or PS 1.5 J6 | COM1 19-pin receptacle to
CLC-10 RJ-11 comms jack
(Cable and CLC-10 are furnished as part of optional CEFD KIT KT-0020518 )
A-2 CA-0000352
Ethernet Interface Cable
(19-pin circular connector to <2X>
RJ-45)
Connecting standalone LPOD-R PS 1 or PS 1.5 J6 | COM1 19-pin receptacle to
LPODnet or user PC Ethernet jack (Cable and LPODnet are furnished as part of
optional CEFD KIT KT-0000203 )
A-3
PP/CAT5FF7FTG
Y CAT5 Ethernet Cable
(RJ-45 to RJ-45)
Connecting standalone LPOD-R PS .5 J6 | COM1 RJ-45 receptacle to LPODnet or
user PC Ethernet jack
( LPODnet is furnished as part of optional CEFD KIT KT-0000203 )
