4–1
Chapter 4. ETHERNET-BASED
REMOTE PRODUCT
MANAGEMENT
4.1 Introduction
Ethernet remote monitor and control (M&C) of the LPOD-R PS .5 is available through its
100BaseT/10BaseTx Ethernet Management Interface by connecting the User PC Ethernet port to
the J6 | COM1 RJ-45 port on the LPOD-R.
Three protocols are available to use for Ethernet remote M&C. Operate these protocols
separately.
• Simple Network Management Protocol (SNMP). This requires a user-supplied Network
Management System (NMS) and a user-supplied Management Information Base (MIB) File
Browser.
• Telnet Interface. This requires use of the User PC’s Command line interface, or a user-
supplied terminal emulation program, such as HyperTerminal.
• Web Server (HTTP) Interface. This requires a compatible user-supplied web browser such as
Internet Explorer.
4.1.1 Prerequisites
Before you proceed with Ethernet remote product management, make sure the following is
true:
• The LPOD-R is operating with the latest version firmware files.
• The User PC is running a terminal emulation program for operation of the LPOD-R Telnet
Interface.
• The User PC is running a compatible web browser for operation of the LPOD-R Web Server
Interface.
• The user-supplied Windows PC is connected to the LPOD-R as applicable:
o
PS 0.5: The J6 | COM1 port on the unit connects to the User PC Ethernet port with a
user-provided Ethernet cable that has the available weatherproof connector kit (CEFD
P/N KT-0020707 or KT-0020708).
