LPOD-R Outdoor Amplifier / Block Up Converter (BUC) MN-LPODR
Optional Serial-based Remote Product Management Revision 1
5–14
Parameter
Type
Command
(Instruction
Code and
Qualifier)
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are printable ASCII characters)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
Qualifier)
Response to
Query
(Target to
Controller)
Retrieve
Firmware
Number
N/A Query only
Returns the firmware type(s) loaded into the unit in the form FW-AAAAAAA B.B.BB MM/DD/YY, where:
FW-AAAAAAA = the firmware part number
B.B.BB = the version number
MM/DD/YY = Month/Day/Year firmware released
Example:
<1/FRW?’cr’
>0001/FRW=’cr’’lf’
Activefirmware:
FW-0020765;1.1.1mx;03/19/14
Pendingfirmware:
PendingImage INVALID
FRW= FRW? FRW=Activefirm
ware:{CR}abc{C
R}abc
Pendingfirmwar
e:{CR}abc{CR}a
bc
(See Description
of Arguments for
details)
Global
Amplifier
Configuration
GAC= 43 bytes Command or Query.
Sets or returns the global status of the BUC/SSPA, response is semicolon delimited in the form a;b;cc.cc;dd.dd;e;fffff;g;
hh;I;j;k;l;m;n;o;’cr’ where:
a = redundancy mode (ESW)
b = online status (ONL)
cc.cc = Attenuation Offset (AOF)
dd.dd = Customer Attenuation(ATT)
e = Auto Fault Recovery (AFR)
fffff = Unit Alarm Mask (MSK)
g = LNB Current Source (LCS)
hh = LNB Current Window (LCW)
i = LNB Current Window Enable (CWE)
j = Enable Statistics Averaging (ESA)
k = Set Statistics Interval (SSI)
l = Enable Statistics Logging (ESL)
m = Auxiliary Mute (AUX)
n = user mute state (MUT)
o = RF power amplifier state (AMP)
Note: Unused fields are padded with X’s.
GAC=
GAC*
GAC?
GAC#
GAC? GAC=x….x
(See Description
of Arguments for
details)
Initialize
Events
Pointer
IEP= None Command only.
Resets internal pointer to allow RNE? queries to start at the beginning of the stored events log.
Example: <1/IEP=’cr’
>0001/IEP=’cr’’lf’
IEP=
IEP?
IEP*
N/A N/A
