Comtech EF Data LPOD-R - Manual (Page 91)

LPOD-R Outdoor Amplifier / Block Up Converter MN-LPODR
Ethernet-based Remote Product Management Revision 1
4–5
To see the full response messages, you can use the HyperTerminal terminal emulation program
configured as a Telnet client.
Configure HyperTerminal as follows:
1. Make sure to define the Connect To Telnet connection properties correctly (File 
Properties):
A) Enter the LPOD-R’s Traffic/Management IP Address as the Host address (e.g.,
192.168.1.1).
B) Enter TCP Port 23 as the Port number.
C) Set Connect using to TCP/IP (Winsock) instead of COM1 or COM2.
2. For ASCII Setup (File  Properties  Settings  ASCII Setup):
A) Check the Send line ends with line feeds option in the ASCII Sending section.
B) Check the Append line feeds to incoming line ends option in the ASCII Receiving
section.
Examples of login and remote command/query execution, when using HyperTerminal as the
interface, follow:
