DD2401 VME L-Band Demodulator Card Installation & Operational Manual Technical Specifications
MN-VME2401 – Rev. B 7-11
2/3 Rate 2/3 Rate w/RS 2/3 Rate 2/3 Rate w/RS
1E-3 6.3 dB 5.8 dB 4.8 dB 4.9 dB
1E-4 7.3 dB 6.1 dB 5.6 dB 5.1 dB
1E-5 8.2 dB 6.3 dB 6.4 dB 5.4 dB
1E-6 9 dB 6.5 dB 7.2 dB 5.6 dB
1E-7 9.8 dB 6.7 dB 8.1 dB 5.8 dB
1E-8 10.4 dB 6.9 dB 8.9 dB 6.1 dB
1E-9 11.1 dB 7.1 dB 9.7 dB 6.3 dB
1E-10 11.9 dB 7.3 dB 10.5 dB 6.6 dB
BER
Table 7-4 - 8PSK BER Performance (Trellis)
Specification Typical
Turbo 0.495 Turbo 0.793 Turbo 0.495 Turbo 0.793
1E-3 - 7 dB 4.2 dB 5.4 dB
1E-4 - 7.3 dB 4.3 dB 5.6 dB
1E-5 - 7.7 dB 4.5 dB 5.9 dB
1E-6 - 8 dB 4.6 dB 6.2 dB
1E-7 - 8.4 dB 4.7 dB 6.4 dB
1E-8 - 8.7 dB 4.9 dB 6.7 dB
1E-9 - 9.1 dB 5 dB 7 dB
1E-10 - 9.5 dB 5.2 dB 7.3 dB
Table 7-5 - 8PSK BER Performance (Turbo)
Typical BER Specification
1/2 Rate 3/4 Rate 7/8 Rate 1/2 Rate 3/4 Rate 7/8 Rate
1E-3 - 3.2 dB 4 dB - 2.8 dB 3.7 dB
1E-4 - 3.4 dB 4.1 dB - 3 dB 3.8 dB
1E-5 2.7 dB 3.6 dB 4.2 dB 2.4 dB 3.2 dB 3.9 dB
1E-6 2.9 dB 3.8 dB 4.3 dB 2.6 dB 3.4 dB 4 dB
1E-7 3.1 dB 4.1 dB 4.4 dB 2.8 dB 3.7 dB 4.1 dB
1E-8 3.3 dB 4.4 dB 4.5 dB 3 dB 4 dB 4.2 dB
Table 7-6 - (O)QPSK BER Performance (Turbo)
BER Specification Typical
3/4 Rate 7/8 Rate 3/4 Rate 7/8 Rate
1E-3 5.6 dB 6.7 dB 5.4 dB 6.3 dB
1E-4 5.8 dB 6.8 dB 5.6 dB 6.4 dB
1E-5 6 dB 6.9 dB 5.8 dB 6.5 dB
1E-6 6.2 dB 7 dB 6 dB 6.6 dB
1E-7 6.4 dB 7.1 dB 6.2 dB 6.7 dB
1E-8 6.8 dB 7.2 dB 6.6 dB 6.8 dB
Table 7-7 - 8PSK BER Performance (Turbo)
BER Specification Typical
