User Interfaces

DD2401 VME L-Band Demodulator Card Installation & Operational Manual

4-24

MN-VME2401 – Rev. B

<1>

<4>

<2>

<4>

Latched Alarm 2

Latched Alarm 3

Latched Alarm 4

Latched Common
Alarm

Reserved

Error Counter

Test 2047 Error
Counter

Raw BER
Mantissa

Corrected BER
Mantissa

EbNo

Offset Frequency

Bit 0 = Buffer Underflow
Bit 1 = Buffer Overflow
Bit 2 = Buffer Under 10%
Bit 3 = Buffer Over 90%
Bit 4 = Rx FPGA Configuration Fault
Bit 5 = Rx LNB Fault, LBST Only
Bits 6 - 7 = Spares
(0 = Pass, 1 = Fail)

Bit 0 = IF Synthesizer Lock Detect Fault
Bit 1 = Rx Oversample PLL Lock Detect Fault
Bit 2 = Buffer Clock PLL Lock Detect Fault
Bit 3 = Viterbi Decoder Lock Fault
Bit 4 = Sequential Decoder Lock Fault
Bit 5 = Rx 2047 Test Pattern Lock Fault
Bit 6 = External Reference PLL Lock Fault
Bit 7 = Frame Sync/Multiframe Sync Fault
(0 = Pass, 1 = Fail)

Bit 0 = Buffer Clock Activity Detect Fault
Bit 1 = External BNC Activity Detect Fault
Bit 2 = Rx Satellite Clock Activity Detect Fault
Bit 3 = External Reference PLL Activity Fault
Bit 4 = High Stability Activity Detect Fault
Bit 5 = High Stability PLL Fault
Bit 6 = Eb/No Threshold Fault
Bit 7 = Spare
(0 = Pass, 1 = Fail)

Bit 0 = -12 V Alarm
Bit 1 = +12 V Alarm
Bit 2 = +5 V Alarm
Bit 3 = Temperature Fault
Bit 4 = Interface FPGA Fault
Bit 5 = Battery Fault
Bit 6 = RAM/ROM Fault
Bit 7 = Spare
(0 = Pass, 1 = Fail)

Ignore

Unsigned Binary Value

Unsigned Binary Value

Bytes 1 - 2 = Unsigned Binary Value Raw BER

Bytes 1 - 2 = Unsigned Binary Value Corrected BER

Unsigned Binary Value, 2 Decimal Places Implied

Unsigned Binary Value in Hz, Pos/Neg Indicated Below
