User Interfaces DD2401 VME L-Band Demodulator Card Installation & Operational Manual
4-32 MN-VME2401 – Rev. B
*<1>
*<1>
*<1>
<1>
<1>
*<1>
*<1>
*<1>
*<1>
Async Terrestrial
Interface Type
Multiprotocol
Interface Card
Interface Type
G.703 Interface
Type
BPSK Symbol
Pairing
Receive Mode
T1/E1 Frame
Source
Receive IDR
Overhead Mode
Receive IDR /
IBS Backward
Alarms Mask
Interface Type
interface card is installed. If not, set to zero.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a synchronous
Multiprotocol interface card is installed. If not, set to zero.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a symmetric G.703
interface card is installed. If not, set to zero.
0 = G703T1AMI, 1 = G703T1B8ZS, 2 = G703BE1, 3 = G703UE1
Note: The following byte applies to all DMD2401 modems,
regardless of interface type
0 = Normal, 1 = Swapped
Note: The following byte applies only if an IDR OR IBS interface
card is installed. If not, set to zero.
0 = Closed Net Mode, 1 = IDR Mode, 2 = IBS Mode, 3 = Drop & Insert
Mode
Note: The following byte applies only if an IDR OR IBS interface
card is installed and the Receive Mode is set to IDR Mode. If not,
set to zero.
0 = Internal, 1 = External
Note: The following byte applies only if an IDR OR IBS
interface card is installed and the Receive Mode is set to
IDR Mode. If not, set to zero.
0 = Voice, 1 = 64 K data
Bit 0 = IDR Backward Alarm 1 / IBS Backward Alarm
Bit 1 = IDR Backward Alarm 2
Bit 2 = IDR Backward Alarm 3
Bit 3 = IDR Backward Alarm 4
Bits 4 - 7 = Spares
(0 = Mask, 1 = Allow)
Note: The following byte applies only if an IDR OR IBS interface
card is installed and the Receive Mode is set to IDR Mode. If not,
set to zero.
If G.703 daughter card installed:
