Rear Panel Interfaces DD2401 VME L-Band Demodulator Card Installation & Operational Manual
5-2 MN-VME2401 – Rev. B
5.1 Power
Table 5-1. Power (P1) – DIN 96 Male
Pin No. Signal Name Description Direction
A32,B32, C32 +5V +5V In
A31 -12V -12V In
C31 +12V +12V In
A9, C9, A11, A15, A17, A19, B20, B23 GND Ground -----
5.1.1 Diagnostic LED’s
Table 5-2. Diagnostic LED’s
Pin No. Description
D10 Receiver Fault
D11 Receiver on – Carrier Detect
D7 Sequential Xilinx Configuration
D8 Reed Solomon Xilinx Configuration
D9 RX Buffer Xilinx Configuration
D3 Viterbi
D4 Sequential Lock
D5 Demod Lock
D6 Reed Solomon Lock
