DD2401 VME L-Band Demodulator Card Installation & Operational Manual User Interfaces
MN-VME2401 – Rev. B 4-9
computer or to another device, that can originate from and are interpreted by all Radyne
equipment in the same manner. These are summarized as follows (all opcode values are
expressed in decimal form):
Table 4-5. Response Opcodes
Response Opcode Description Opcode
Good Message 0000h
Bad Parameter 00FFh
Bad Opcode 00FEh
Bad Checksum 00FDh
Command Not Allowed in LOCAL Mode 00FCh
Command Not Allowed in AUTO Mode 00FBh
Bad Destination 00FAh
Unable to Process Command 00F9h
Packet Too Long 00F8h
The following response error codes are specific to the DD2401/DD2401L:
Response Opcode Description Opcode
DPARM_MODE_ERROR 0x0600
DPARM_FREQUENCY_ERROR 0x0601
DPARM_DATARATE_ERROR 0x0603
DPARM_SWEEPBOUNDARY_ERROR 0x0604
DPARM_LEVELLIMIT_ERROR 0x0605
DPARM_DEMODULATIONTYPE_ERROR 0x0608
DPARM_CONVDECODER_ERROR 0x0609
DPARM_REEDSOLOMON_ERROR 0x060A
DPARM_DIFFERENTIALDECODER_ERROR 0x060B
DPARM_DESCRAMBLERCONTROL_ERROR 0x060C
DPARM_DESCRAMBLERTYPE_ERROR 0x060D
DPARM_SPECTRUM_ERROR 0x060E
DPARM_BUFFERCLOCK_ERROR 0x0610
DPARM_BUFFERCLOCKPOL_ERROR 0x0611
DPARM_INSERTMODE_ERROR 0x0612
DPARM_FRAMING_ERROR 0x0615
DPARM_OPERATINGMODE_ERROR 0x0616
DPARM_BERMEASUREPERIOD_ERROR 0x0619
DPARM_CIRCUITID_ERROR 0x061A
DPARM_TERRLOOPBACK_ERROR 0x061B
DPARM_BASELOOPBACK_ERROR 0x061C
DPARM_IFLOOPBACK_ERROR 0x061D
DPARM_INTERFACETYPE_ERROR 0x061E
DPARM_NOTIMPLEMENTED_ERROR 0x0622
DPARM_DATAINVERT_ERROR 0x0623
DPARM_SUMMARYFAULT_ERROR 0x0624
DPARM_EXTERNALEXCSOURCE_ERROR 0x0625
DPARM_BUFFERSIZEMSEC_ERROR 0x0629
DPARM_BUFFERSIZEBYTES_ERROR 0x062A
DPARM_ASYNCINTERFACETYPE_ERROR 0x0630
DPARM_BUFFERSIZEMSECBYTES_ERROR 0x0631
DPARM_IMPEDANCE_ERROR 0x0632
DPARM_INTERLEAVER_ERROR 0x0635
MDPARM_TIME_ERROR 0x0A01
MDPARM_DATE_ERROR 0x0A02
