DD2401 VME L-Band Demodulator Card Installation & Operational Manual User Interfaces
MN-VME2401 – Rev. B 4-39
Opcode: <2C07h> Command soft reset the modem to the power-up state (no parameters).
Opcode: <2C08h> Commend Eb/No Threshold
<1> Eb/No
Threshold Unsigned Binary Value, 0-99, Implied Decimal Point
0.0 through 9.9 dB
Opcode: <2C30h>
Command Module Set Default Configuration (No Parameters)
4.4.12.3 Default Values Demodulator
Opcode: <2A00h> Command a Demodulator’s Configuration
<4>
<4>
<1>
<4>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<1>
<4>
Frequency
Data Rate
Sweep Boundary
External
Reference
Ext Reference
Source
Input Level Limit
Demodulation
Type
Convolutional
Decoder
Reed-Solomon
Reed-Solomon N
Reed-Solomon K
Reed-Solomon T
RS Interleaver
Depth
Differential
Decoder
Descrambler
Control
Descrambler
Type
Spectrum
Buffer Size
70,000,000 Hz
140,000,000 Hz (**)
950,000,000 Hz
(Hardware dependant)
**Legacy 100-180 MHz only
2,048,000 BPS
25 kHz
10,000,000 Hz
0 = Internal
-90 dBm
0 = QPSK
1 = Viterbi ½ Rate
0 = Disable
126
112
7
4
1 = On
1 = Enable
2 = V35_IESS
<04> <2C> <1D> <80>
<08> <58> <3B> <00>
<38> <9F> <80>
<00> <1F> <40> <00>
<19>
<00> <98> <96> <80>
<00>
<5A>
<00>
<01>
<00>
<7E>
<70>
<07>
<04>
<01>
<01>
<02>
<00>
<00> <01>
