DD2401 VME L-Band Demodulator Card Installation & Operational Manual User Interfaces
MN-VME2401 – Rev. B 4-17
*<1>
*<1>
*<1>
*<1>
*<1>
*<1>
<1>
<1>
*<1>
Async Framing
Async Baud Rate
Async Port Type
Async Terrestrial
Interface Type
Multiprotocol
Interface Card
Interface Type
G.703 Interface
Type
BPSK Symbol
Pairing
Receive Mode
T1/E1 Frame
Source
Note: The following byte applies only if an Asynchronous, IDR
or IBS Interface is installed. If not, ignore.
0 = No Framing, 1 = 1/16 Async, 2 = 1/16 IBS, 3 = 96 Kbit IDR
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = 1200, 1 = 2400, 2 = 4800, 3 = 9600, 4 = 19200, 5 = 50, 6 = 110,
7 = 300, 8 = 600
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = RS-232, 1 = RS-485
Note: The following byte applies only if an asynchronous
interface card is installed. If not, ignore.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a synchronous
Multiprotocol interface card is installed. If not, ignore.
0 = V.35, 1 = RS-422, 2 = RS-232
Note: The following byte applies only if a symmetric G.703
interface card is installed. If not, ignore.
0 = G703T1AMI, 1 = G703T1B8ZS, 2 = G703BE1, 3 = G703UE1
Note: The following byte applies to all DMD2401 modems,
regardless of interface type.
0 = Normal, 1 = Swapped
Note: The following byte applies only if an IDR OR IBS
interface card is installed. If not, ignore.
0 = Closed Net Mode, 1 = IDR Mode, 2 = IBS Mode, 3 = D&I Mode
Note: The following byte applies only if an IDR OR IBS
interface card is installed and the Receive Mode is set to
IDR Mode. If not, ignore
0 = Internal, 1 = External
Note: The following byte applies only if an IDR OR IBS
interface card is installed and the Receive Mode is set to
IDR Mode. If not, ignore
