Installation MINIMAC Rack Management System
2–4 Rev. 0
2.3 Fabrication of Remote Cables
Refer to (Table 2-1) for a listing of cables that can be fabricated for the MiniMAC
system.
Table 2-1. Fabrication of Remote Cables
Cable (From/To)
Pin
Configuration Reference
Star Gate RS-485 (2-wire) MiniMAC to Remote 9-pin to 9-pin Figure 2-1
Star Gate RS-485 (2-wire) MiniMAC to ASYNC 9-pin to 25-pin Figure 2-2
Remote Site RS-485 (2-wire) Device Remote to ASYNC 9-pin to 25-pin Figure 2-3
Remote Site RS-485 (2-wire) Wire ASYNC to Dual Remote 25-pin to 9-pin Figure 2-4
Star Gate RS-485 (2-wire) MiniMAC to RSU-503R Rack
Switch Cable 9-pin to 25-pin Figure 2-5
Star Gate RS-485 (2-wire) MiniMAC to Remote 9-pin to 26-pin
Circular
Figure 2-6
ESC ASYNC RS-485 (2-Wire) Remote Y-Cable 25-pin to 9-pin
to 26-pin circular
Figure 2-7
Star Gate RS-232 MiniMAC Cables Table 2-2
MOXA to Modem (or Switch Remote) Port Cable RS-485
(4-wire) 25-pin to 9-pin Table 2-3
MOXA to ASYNC Port (ESC) Cable RS-422 (4-wire) 25-pin to 25-pin Table 2-3
MOXA RS-232 MiniMAC Cables Table 2-4
