Network load control
PSSnet SHL - Basic Configuration
Pilz GmbH & Co. KG, Felix- Wankel Str. 2, 73760 Ostfildern
8.4 QoS/Priority
129
„
Configuring Layer 3 management priority
Select the QoS/Priority:Global dialog.
In the line IP-DSCP value for management packets you enter
the IP-DSCP value with which the device sends management pack-
ets.
enable Switch to the Privileged EXEC mode.
network priority ip-dscp
cs7 Assign the value cs7 to the management priority so
that management packets with the highest priority
are handled.
exit Switch to the privileged EXEC mode.
show network Displays the management VLAN priority.
System IP Address.............................. 10.0.1.116Subnet
Mask.................................... 255.255.255.0Default
Gateway................................ 10.0.1.200Burned In MAC
Address.......................... 00:80:63:51:7A:80Network Config-
uration Protocol (BootP/DHCP).... NoneDHCP Client ID (same as SNMP
System Name)...... "PowerMICE-518280"Network Configuration Proto-
col HiDiscovery..... Read-WriteManagement VLAN
ID............................. 1Management VLAN Priori-
ty....................... 7Management IP-DSCP Val-
ue....................... 56(cs7)Web
Mode....................................... EnableJavaScript
Mode................................ Enable
