4-3
4.2 Configuration
4 Function description
4.2.1 Scaling
Scaling 4- ][Funktionsbeschreibung_BA_Konfig Skalier Ein bersicht
Scaling is a multi-stage process to adapt the values from the AD con-
verter. The straight path in the diagram indicates the default configura-
tion.
ADC
raw value
Raw value
output?
Manuf.
scaling
active?
Hardware
calibration
Manufacturer
scaling
User
scaling
active?
User
scaling
Output
formats
N
Y
Y
Y N
N
