2006-2010 Jeep Grand Cherokee
Part No. 4CK218-020L/-028L
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or
damaged parts immediately.
PARTS LIST
®
ENGINEERING, INC
008110 SMALL SILVER DIE CUT DECAL 2
008130 LICENSE PLATE FRAME, VORTECH 1
008341 POWERCOOLER DECAL 1
008447 S/C STREET PACKAGE ASSEMBLY 1
009035 S/C LUBE, BOTTLED, VORT 3-PACK 1
2A046-975 BELT K060975, JEEP HEMI 1
2F329-190(8) S/C ASSY, V3 CCW SI STR 1
4GR033-032 PULLEY, SC, C5, 20MM, 32T 1
7A312-125 5/16-18 X 1 1/4 GR5 HHCS, ZINC 2
4GS012-030(8) DUCT, CAC TO TBODY, C6 1
7J312-000 5/16 FLAT WASHER-SAE 2
7R005-001 CLAMP, T-BOLT, 208-91 1
4CK020-010 MANUAL, JEEP GRAND HEMI 1
4CK110-044 S/C MTG BRKT ASSY, JGC 1
008725 CAP, TAMPER PROOF, VORT S/C 2
2A017-093 SPACER, S/C PULLEY, .093" 1
2A017-102-181 SPACER, 1"OD X .406 ID X 1.809 1
2A017-105-197 SPACER,1"OD,.328"ID,1.974"L 6
2A017-105-198 SPACER,1"OD,.328" ID,1.974"L,STEPPED 1
2A017-105-290 SPACER,1.00" O.D. X .328" I.D. AL 2
2A017-154 SPACER, .154", IDLER BRG 1
2A017-375 SPACER, .375, C6, IDLER 2
2A036-333 S/C PULLEY 3.33" 6 GROOVE 1
2A040-051 PLY RETAINER, TAMPER PRF CAP 2
2A040-061 RETAINER CUP, VORT S/C PLY 2
2A042-080 BELT, GATES 20MM, 80 TOOTH 1
2D070-159 LARGE BEARING,EXTENDED DRIVE 2
2D070-171 JACKSHAFT, C5, H900 1
4CJ017-021 SPACER, .625" COIL 3
4CK010-010 PLATE, HEAD MTG, 08 JGC 1
4CK010-020 BRKT, LOWER, IDLER-SC PLT, 08 JGC 1
4CK010-030 BRKT, UPPER, WTR PMP-SC PLT, 08 JGC 1
4CK010-044 PLATE,SC MTG, 08 JGC 1
4GR032-032 PULLEY,JACKSHAFT,C5,20MM,32T 1
4GR116-300 IDLER ASSY, 20MM BELT 2
4NZ030-041 BRG HSG, 350Z 1
7A312-152 5/16-18 X 1.5 SHCS, ZN PLT 4
7A312-300 5/16-18 X 3" HXHD 1
7A312-401 5/16-18 X 4" HXHD 2
7A312-675 5/16-18 X 6.75" STUD 2
7A375-300 3/8-16 X 3" HXCSG5P 1
7B375-075 3/8-24 X 3/4" GR8 HXHD BOLT 1
7B375-150 3/8-24X 1-1/2 GR8 HX 1
7C010-025 M10-1.5X25MM HXCP 1
7C010-162 M10 X 160MM STUD 1
7C012-022 M12 X 1.75 X 20MM THIN HD 3
7C012-065 M12 X 1.75 X 65MM HX 1
7C080-020 M8 X 1.25 X 20 HXHD, PLTD 1
7C080-090 M8 X 1.25 X 90 HXHD CL10.9 1
7C080-100 M8 X 1.25 X 100 HXHD ZN PLT 1
7F312-018 5/16-18 NUT USS PLTD 2
7G010-175 12MM X 1.75 NUT 1
7GL10-150 10M X 1.5 NUT NYLOCK 1
7J012-092 12MM WASHER, FLAT 2
7J312-000 5/16 FLAT WASHER-SAE 8
7J375-044 3/8 SAE WASHER, PLTD 3
7U100-069 KEY, 3/16 SQUARE X .73 LONG 1
7U100-073 KEY, 3/16 SQUARE X 1.375 LONG 1
7U100-084 SNAP RING,V9 1
7X100-027 WAVE WASHER-LARGE (V-2) 1
4CK112-010* AIR INLET ASSY, HEMI JGC 1
*SEE PAGE VIII FOR ASSEMBLY COMPONENTS
4CK112-020* AIR DISCHARGE ASSY, HEMI JGC 1
*SEE PAGE VIII FOR ASSEMBLY COMPONENTS
4CL110-110* ASSY, DAMPER PIN HEMI 1
*SEE PAGE VIII FOR ASSEMBLY COMPONENTS
8D204-010(06) RACE BYPASS VALVE-BLACK 1
8N301-270(8) WELDED CLR ASSY, HEMI JGC 1
4CK110-100 FUEL SYSTEM ASSY, JGC 1
4CK010-080 BRKT, MAP MOUNT, JGC 1
4CL010-030 MAP SENSOR BLOCK, 07 CHARGER 1
4FR017-061 SPCR, H20 PIPE ASY, 03 MACH 1
5A002-017 MAP SENSOR, 07 CHARGER SC 1
7C010-077 10-24X3/4 BUTTON HD,CAP SCREW 2
7E010-150 #10 X 1.5" SHEET METAL SCREW 4
7F006-093 6MM NYLOCK NUT 1
7J250-001 1/4 WASHER, SAE, PLTD 1
7P062-187 1/16NPT X 3/16 HOSE BARB 1
7P250-045 1/4 MALE NPT X 3/8 MALE BARB 2
7R001-006 #6 STNLS HOSE CLAMP, NARROW 5
7U031-016 5/16" PCV/VAC RUBBER HOSE 2'
7U032-016 3/8" EFI FUEL HSE HI-PSR 4'
8F060-008 FUEL INJ, 07 CHARGER SC 8
5A003-050 DIABLO PREDATOR, HEMI 1
5A102-032 ASSY, VOLT BOOST JEEP SRT8 G3 1
5A002-031 VOLT BOOSTER HEMI G3 1
5W001-021 1/2" SPLIT PLASTIC WIRE LOOM 7'
5W001-005 3/8" SPLIT PLASTIC WIRE LOOM 11'
5W001-032 1/4" SPLIT PLASTIC WIRE LOOM 5'
5W010-000 10GA RED STRANDED WIRE 19'
5W012-010 12GA BLACK STRANDED WIRE 9'
5W012-080 12GA ORANGE STRANDED WIRE 9'
5W014-010 14GA RED STRANDED WIRE 9'
7U030-024 1/8" NYLON INSTRUMENT TUBING 20'
7P156-082 5/32" TEE 1
7U030-109 7/64" VAC HOST .5'
7U100-044 4" NYLON TIE WRAPS 10
7U100-055 7.5" NYLON TIE WRAPS 10
5W001-014 FUSE HOLDER 10GA WIRE 1
7E010-048 #10 SHEET METAL PHILLIPS HEAD 3
7E010-075 #12 SHEET METAL HEX HEAD 2
5W001-007 3/16 HEAT SHRINK .75'
5W001-038 1/4 HEAT SHRINK .75'
5W001-043 10-12GA 1/4" YELLOW RING TERMINAL 1
5W001-041 10-12GA YELLOW SLIDE CONNECTOR MALE 2
5W001-040 10-12GA YELLOW SLIDE CONNECTOR FEMALE 3
5W001-019 10-12GA YELLOW BUTT CONNECTOR 2
5W001-009 14-16GA BLUE SLIDE CONNECTOR MALE 2
5W001-010 14-16GA BLUE SLIDE CONNECTOR FEMALE 3
5W001-013 14-16GA BLUE BUTT CONNECTOR 1
5W001-011 14-16GA BLUE RING TERMINAL 2
PART NO. DESCRIPTION QTY PART NO. DESCRIPTION QTY
