Stackable NWay Ethernet Switch User’s Guide
88
Using the Console Interface
♦
IP Address The IP address of the network management station to receive traps.
Switch Monitoring
The Switch uses an SNMP agent which monitors different aspects of network traffic. The SNMP agent keeps
counters and statistics on the operation of the Switch itself, and on each port on the Switch. The statistics
obtained can be used to monitor the conditions and general efficiency of the Switch.
Network Monitoring
The Network Monitoring menu offers four items, Traffic Statistics, Browse Address Table, Switch
History, and Browse IGMP Status.
Choose Network Monitoring from the main menu. The following menu appears:
Figure 6-44. Network Monitoring menu
The first item on this menu permits you to access four different tables that observe the condition of each
individual port.
