D-Link DES-3624 - Manual (Page 150)

Stackable NWay Ethernet Switch User’s Guide
150 Technical Specifications
General
Network
Cables:
10BASE-T:
2-pair UTP Cat. 3,4,5 (100 m)
EIA/TIA- 568 100-ohm STP (100 m)
100BASE-TX:
2-pair or 4-pair UTP Cat. 5 (100 m)
EIA/TIA-568 100-ohm STP (100 m)
100BASE-FX
50µm and 62.5µ
m
multi-mode fiber
1000BASE-SX:
50µm and 62.5µm multi-mode fiber
1000BASE-LX:
50µm and 62.5µm multi-mode fiber or 10µ
m
single-
mode fiber
Number of
Ports:
24x or 22x 10/100 Mbps NWay ports
Media
Interface
Exchange:
Connectors 1x and 2x in client devices are MDI-X jacks
for ports 1 and 2. Connector 1x in the master device is
an MDI-X jack for port 1.
Physical and Environmental
AC inputs: 100 - 240 VAC, 50~60 Hz (internal universal power
supply)
Power
Consumption:
46 watts maximum
DC fans: 2 built-in 40 x 40 mm fan
Operating
Temperature:
0 to 50 degrees Celsius
Storage
Temperature:
-25 to 55 degrees Celsius
Humidity: Operating: 5% to 95% RH non-condensing;
Storage: 0% to 95% RH non-condensing
Dimensions: 441 mm x 367 mm x 44 mm (1U), 19 inch rack-mount
width
Weight: 5 kg
EMI: FCC Class A, CE Class A, VCCI Class A, BSMI Class
A, C-Tick Class A
Safety: UL, CSA, TUV/GS
