Stackable NWay Ethernet Switch User’s Guide
Web-Based Network Management 101
Clicking on one of the ports opens a configuration window for that particular port.
Each page contains the following list of buttons in the panel on the left side: Configuration, Management,
Monitoring, and Maintenance. These are the main categories for Switch management. Clicking on one of
the categories causes a list of options to appear below.
The switch management features are explained below.
Configuration
This first category includes: IP Address, Switch (Advanced and Switch Unit), Port, Port Trunk, Port
Mirroring, Spanning Tree Protocol (STP Parameter Setting and STP Custom Setting), Forwarding
and Filtering (Static Forwarding Table, MAC Address Filtering Table, and Permanent Multicast
Filtering), IGMP (IGMP Settings and 802.1Q IGMP), and VLANs & MAC-based Broadcast Domains
(MAC-based Broadcast Domains and IEE 802.1Q VLANs), as well as a number of related windows.
IP Address
Figure 7-1. Configure IP Address window
