MAB max. 86.5 x 128.5 x 60.0 1 Carrier with integrated
temperature sensor, without
bottom window, suitable for
rotor no. 124700 with carrier
no. 124706
124703
MAB max. 86.5 x 128.5 x 60.0 1 Carrier without temperature
sensor, without bottom
window, suitable for
rotor no. 124700 with carrier
no. 124703
124706
4 40 Massive bucket, with thicker
rim and pedestal, for vessels
10,2 x 45,5 mm, suitable
for 124703 and 124706
112290
DWP max. 86.5 x 128.5 x 60.0 1 Carrier with integrated
temperature sensor, with
bottom window, suitable for
rotor no. 124700 with carrier
no. 124707
124711 1)
DWP
or
MAB
max. 86.5 x 128.5 x 60.0
max. 86.5 x 128.5 x 60.0 1
1 Carrier without temperature
sensor, with bottom window,
suitable for rotor no. 124700
with carrier no. 124711 and
124702
124707
MAB max. 86.5 x 128.5 x 60.0
1 Carrier with integrated
temperature sensor, with
bottom window, suitable for
rotor no. 124700 with carrier
no. 124702
The temperature sensor is
positioned at the location hole
of the massive bucket
124702
4 48 Massive bucket, for vessels
11.0-11.7 x 28.0-33.0 mm,
suitable for 124702 and
124707
110535
4 35 Frame, for vessels
12.0-12.8 x 53.2-64.2 mm,
suitable for 124702 and
124707
113309
