4 Storage and transport
Pos: 75 / 200 Christ /37 0 RVC-BA (STANDARDM ODULE)/ 040 Lag eru ng u nd Tra nsp ort/ 040 -00 10 Lag erb eding ung en @ 25\ mod _14 049 850 615 72_ 68.d ocx @ 186 967 @ 2 @ 1
4.1 Storage conditions
In order to ensure the protection against mechanical and climatic
influences, the guidelines of the German Federal Association for Wooden
Packages, Pallets, and Export Packaging (Bundesverband Holzpackmittel,
Paletten, Exportverpackung e.V.), the so-called HPE packaging guidelines,
must be applied when packing and storing the RVC.
The storage must be:
• dust-free
• dry
• free from excessive temperature fluctuations
• free from mechanical load.
Pos: 76 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 77 / 200 Christ /37 1 RVC-BA (PROJEKTE) /RVC 2-3 3 IR/ 040 Lag eru ng u nd Tr ansp ort/ 040 -00 10 Ab mess ung en u nd G ewicht RVC 2-3 3 IR @ 31\ mod _14 074 840 464 96_ 68.d ocx @ 208 957 @ 2 @ 1
4.2 Dimensions and weight
Values for the RVC without a vacuum pump:
RVC 2-33 IR
Height:
315 mm
Height with open lid:
715 mm
Width:
550 mm
Depth (incl. vacuum flange connection):
536 mm
Weight:
approx. 49 kg
Pos: 78 / 010 Unive rsalm odul e/Le erzeil e @ 0\mo d_1 202 116 244 500 _0.d ocx @ 114 @ @ 1
Pos: 79 / 200 Christ /37 1 RVC-BA (PROJEKTE) /RVC 2-3 3 IR/ 040 Lag eru ng u nd Tr ansp ort/ 040 -00 30 Ve rpa ckun g RVC 2- 33 IR @ 3 1\mo d_1 407 484 046 781 _68. docx @ 20 897 1 @ 2 @ 1
4.3 Packaging
The RVC is packaged in a cardboard box or in a wooden crate, depending
on the scope of supply.
• After opening the packaging, take out the box containing the
accessories.
• Remove the packaging material.
• Lift the RVC upwards and out of the crate/cardboard box. When lifting
the unit, always reach under it from the side.
CAUTION
The RVC 2-33 IR weighs approx. 49 kg!
