70
Appendix C: RapidVap Specifications
Product Service Domestic 1-800-522-7658, International 816-333-8811
300 ml, the vortex speed must be reduced and the nitrogen
pressure must be decreased to prevent the sample from
splashing out. This data for starting volumes over 300 ml
was generated by starting the evaporation at reduced levels
of nitrogen pressure and vortex speed. As the solvent
evaporated, the nitrogen pressure and vortex speed were
increased.
Solvent: Methylene
Chloride
Ethyl
Acetate Hexanes Acetone Toluene Water
Block Preheat &
Block Set Point
Temperature:
40°C 75°C 70°C 55°C 100°C 95°C
Starting Volume
450 ml 58 56 33 68 75 420
400 53 48 29 61 63 352
350 48 40 24 54 52 321
300 41 35 21 47 45 266
250 35 31 19 43 40 230
200 30 26 16 38 35 193
150 25 22 14 34 28 153
100 19 17 11 29 22 120
50 10 9 7 16 15 68
Table B
Evaporation Time in Upper Portion of Sample Vial
(600 ml Sample Tubes) (Time in Minutes)
N
Number of samples: 8
Nitrogen pressure: 10 psi at volumes 0 thru 300 ml
(see Note 1)
5 psi at volumes above 300 thru 350 ml
4 psi at volumes above 350 thru 400 ml
2 psi at volumes above 400 thru 450 ml
Vortex speed: 70% at volumes 0 thru 300 ml
(see Note 1) 36% at volumes above 300 thru 450 ml
Sample tubes: Not covered with caps
