68
Appendix C: RapidVap Specifications
Product Service Domestic 1-800-522-7658, International 816-333-8811
Evaporation Time – 16 mm dia. Sample Tube
(Time in Minutes)
Solvent:
Methylene
Chloride Toluene Acetonitrile Water
Block Preheat &
Block Set Point
Temperature:
50°C 80°C 75°C 80°C
Vacuum: 200 mbar 200 mbar 330 mbar 133 mbar
Starting Volume
10 ml 18 25 25 119
8 14 20 22 101
6 10 14 17 72
4 8 12 13 50
2 4 6 7 26
Number of samples: 69
Vortex speed: 95%
Vacuum pump: Labconco model – 79249-00
Rated free air flow – 88 L/min
Max. attainable vacuum – 31 mbar
RapidVap N
2
Models
The following tables indicate the approximate time
required to evaporate various common solvents. Tables A
and B show the average time required to evaporate 8
samples from the selected beginning volume to a level
where the solvent is at the top of the Cool-Zone stem.
Tables C shows the average time to evaporate various
solvents in different length Cool-Zone stems. It shows the
average time for solvents to evaporate from the top of the
stem to the indicated remaining volume when 8 vials are
run simultaneously. The following example illustrates the
use of the charts:
Assume that a starting volume of 300 ml
methylene chloride is placed in a 600 ml
sample vial with a 1.5 ml stem. The vial is
covered with a cap. The desired endpoint
volume is 0.5 ml. From Table A, the time to
evaporate to the top of the stem is 59
minutes. From Table C, the time to
