Chapter 3: Getting Started
Product Service Domestic 1-800-522-7658, International 816-333-8811
Catalog # RapidVap Description
79100-12 RapidVap N
2
/48 Evaporation System – 115V
79100-13 RapidVap N
2
/48 Evaporation System – 230V
79100-14 RapidVap N
2
/48 Evaporation System – 115V with RS 232 Interface
79100-15 RapidVap N
2
/48 Evaporation System – 230V with RS 232 Interface
Plus the Following:
Part #
Component Description
79131-01 Exhaust Hose
19660-00 One (1) Clamp
13364-00
13365-00 Power Cord – 115V
or
Power Cord – 230V
12556-00 Heat Transfer Grease
74901-00 User’s Manual
74488-00 Manifold Guide (3)
19116-00 Washer (3)
74848-00 Cable Assembly RS232 (Models 74100-14, -15)
If you do not receive one or more of the components
listed for your RapidVap, or if any of the components
are damaged, contact Labconco Corporation
immediately for further instructions.
Setting Up Your RapidVap
After you verify the RapidVap components, move your
RapidVap to the location where you want to install it.
Then, follow the steps listed below.
Vacuum Pump Connection
Connect the pump inlet to the fitting at the right hand
rear corner of the RapidVap using the hose and clamps
provided. Route the hose to prevent kinks. Clamp all
connections securely. Plug the pump into the pump
receptacle on the back of the unit and turn the pump
switch on if it is so equipped. When evaporating high
boiling point solvents, a liquid trap should be
positioned between the RapidVap and the vacuum
pump to prevent liquid from entering the pump. It is
recommended that the vacuum pump is located inside a
fume hood. If that is not possible, the exhaust of the
V
