Page 58
54
Appendix A: RapidVap Vacuum and RapidVap N
2
Components
Product Service Domestic 1-800-522-7658, International 816-333-8811
Item Quantity
Part
No.
Description
1 1 13023-00
Switch,
Power
2 4 74953-00
Foot
3 1 79167-00
Fan
Cooling
4
1
74838-00
PCB, Main (RapidVap Vacuum)
4A
1
74838-03
PCB, Main (RapidVap N
2
& RapidVap N
2
/48)
4B
1
74838-04
PCB, Main (RapidVap Vacuum w/RS232)
4C
1
74838-05
PCB, Main (RapidVap N
2
& RapidVap N
2
/48 w/ RS232)
5 8 74887-00
Isolator,
Upper
6 8 74915-00
Isolator,
Lower
7 1 13364-00
Cord,
Power
(115V)
7A 1
13365-00
Cord,
Power
(230V)
8 1 12926-00
Triac
9 1 79176-00
Diode
Bridge
10 1 78252-00
Belt
11 1 12111-00
Motor
--
1
13444-06
Fuse, 12A, Type T, Slow Blow (Not Shown)
RapidVap Vacuum and RapidVap N
2
Components
