Page 40
36
Chapter 4: Using Your RapidVap
Product Service Domestic 1-800-522-7658, International 816-333-8811
RapidVap N
2
Model
1. Display – The liquid crystal display (LCD) shows
set point parameters and actual measured
conditions.
2. Set Point Select Button – To select a parameter to
change, press the set point select button directly
below the parameter.
3. Run/Stop Button – Used to start or stop a run.
4. Decrease Button – When pressed, the last selected
set point will decrease.
5. Increase Button – When pressed, the last selected
set point will increase.
6. Preheat Button – Used to turn on the heaters to
preheat the sample block prior to loading samples.
When pressed during a run, it will switch the end
point alarm from audible to muted or back to
audible. The audible alarm is the default mode
when the RapidVap is powered up.
7. Vacuum Release (Vacuum Model Only) – When
pressed and held, the vacuum valve will open to
break vacuum. This is used to quickly decrease
vacuum should bumping of the sample occur.
1
6
5
4
3
2
