Page 39
35
Chapter 4: Using Your RapidVap
Product Service Domestic 1-800-522-7658, International 816-333-8811
The tables in Appendix C: RapidVap Specifications
indicate approximate times required to evaporate
various common solvents. Actual times must be
determined by the user. The RapidVap can be set to
alarm after a preset period of operation. When the time
expires, the RapidVap will give an audible alarm and
turn off all functions.
RapidVap Controls
The control panel for the RapidVap vacuum model and
the RapidVap N
2
are shown below with a description
about their function.
RapidVap Vacuum Model
V
1
2
4
6
7
3
5
