Chapter 4: Using Your RapidVap
Product Service Domestic 1-800-522-7658, International 816-333-8811
#H[xxx];
Selects the PRE-HEAT SET POINT of program 9 from 30
to 100 C, will get a xxx;yyy’\n’ response for
confirmation.(xxx:pre-heat setpoint, yyy:actual
temperature)
#L[x]; KEY LOCKED when x=1 and UNLOCKED when x=0,
will get a x’\n’ response for confirmation
#N[x] elects the N2 VALVES (if the RapidVap is an N
2
model) of
program 9 from 0,2,4,6,8, will get a x’\n’ response for
confirmation
#M[x]; x=1 will mute the audio alarm; x=0 will allow the audio
alarm to work normally
#E; The RapidVap will respond to this command with a
numeric value as follows :’”1"’=indicates an endpoint has
been reached; “0”=endpoint has not been reached
#e; The RapidVap will respond to this command with a
numeric value as follows: 0=all functions are normal;
“1”=lid is open; “2”=communication problem; “3” and later
numbers will be established later as specific error messages
Note: When controlling the RapidVap using the
RS-232 link, all control parameters will be entered into
program 9.
Note: All of the above commands can be sent with no
numeric value, that is ‘#[command];’ (without value) to
read out the setpoint and actual value without changing
the setpoint.
Note: There is no command for the vacuum release
button on the front panel since this button is momentary
in nature – the “#V0000;” command will bleed the
vacuum chamber to atmospheric pressure.
Note: The above commands can be sent at a maximum
rate of one command per second.
