Labconco RapidVap Vacuum, N2 and N2/48 Evaporation Systems 7910015 User Manual
Page 15
11
Product Service Domestic 1-800-522-7658, International 816-333-8811
C
C
H
H
A
A
P
P
T
T
E
E
R
R
3
3
G
G
E
E
T
T
T
T
I
I
N
N
G
G
S
S
T
T
A
A
R
R
T
T
E
E
D
D
Now that the site for your RapidVap is properly
prepared, you are ready to unpack, inspect, install, and
test your RapidVap. Read this chapter to learn how to:
• unpack and move your RapidVap.
• set up your RapidVap.
• connect the vacuum pump or nitrogen source to
your RapidVap.
• connect the electrical supply source to your
RapidVap.
• properly exhaust your RapidVap.
• calibrate the vacuum sensor.
• solvent safety precautions.
Depending upon which model of RapidVap you are
installing, you will need common hand tools including
a flat blade screw driver, a 7/16" socket and an
adjustable wrench to complete the instructions in this
chapter.
The RapidVap weighs over 70 lbs.
(33 Kg). The carton allows for lifting
with a mechanical lift truck or hand
truck. If you must lift the RapidVap
manually, use at least two (2) persons
and follow safe-lifting guidelines.
!
